Printed Circuit Board Prototype

JWT PCB supply the fast prototyping service with 24 hours(2 layers) /48 hours(4 layers).The gerber files will be inspected and checked that the files complies with our technical spec.Once the files pass audit, our engineer will check again and optimize the files to make production.

The economical solution for circuit board prototypes with 1, 2, 4, 6, 8 or 10 layers, and a small overall area. Our Sales team always shows the best service,  price and production time.

No minimum quantity. You can get your prices instantly after uploading your files to us. Try now!

Item specifics
•         Brand Name:JWT PCB
•         Model Number:PCB,Assembly
•         Min. Line Width:0.153mm/6mil
•         Min. Hole Size:0.2mm+-0.08mm
•         Min. Line Spacing:0.153mm/6mil
•         Copper Thickness:1oz, 2oz,3oz,4oz
•         Base Material: High-Temp.Aluminum,FR4, Flex,Flex-rigid, HDI, Rogers, etc.
•         Board Thickness:0.2,0.4,0.6,0.8,1.0,1.2,1.6,2.0,2.4 mm
•         Surface Finishing:HASL with lead HASL lead free Immersion gold OSP Hard Gold
•         is_customized:Yes
•         Solder Mask:Green Red Yellow Blue White Black Purple Matte black Matte green
•         Silkscreen:White Black

•         Testing:Fly Probe Testing (Free) and A.O.I. testing(free)

Turn time :As fast as 24 hours

The lead time will take 2 – 3 days usually.

If not urgent, HongKong Post Air Mail, EMS, Epacket, Other shipping way are economic with 12-30 days.
If in urgent, Please inform us to use DHL, UPS, Fedex or TNT, according to package weight

We have been providing PCB Manufacture since 2002 in China. We believe our team will provide high quality and low cost service for you.

To make PCB, JWT PCB has the experience and clients are satisfied with our products. If you need, please contact us to get an PCB Instant Quote and for more information about PCB prototype.
